Reliable supplier for MTL4573 isolated barrier, MTL4573  barrier in stock for sale with discount price. Good price with high quality for sale 100% New&Original

MTL4573 – MTL5573 TEMPERATURE CONVERTER THC or RTD input

The MTLx573 converts a low-level dc signal from a temperature sensor mounted in a hazardous area into a 4/20mA current for driving a safearea load. Software selectable features include linearisation, ranging, monitoring, testing and tagging for all thermocouple types and 2-, 3- or 4-wire RTDs. (For thermocouple applications the HAZ-CJC plug on terminals 1–3 includes an integral CJC sensor). Configuration is carried out using a personal computer.

SPECIFICATION

See also common specification

Number of channels

One

Location of signal source

Zone 0, IIC, Hazardous area

Division 1, Groups A-D, hazardous location

RTD excitation current

200µA nominal

Cold junction compensation, THC input

Selectable ON or OFF

Cold junction compensation error

≤ 1.0°C

Common mode rejection

120dB for 240V at 50Hz or 60Hz

Series mode rejection

40dB for 50Hz or 60Hz

Calibration accuracy (at 20°C)

(includes hysteresis, non-linearity and repeatability)

Inputs:

mV/THC: ± 15µV or ± 0.05% of input value

(whichever is greater)

Pt 100 - RTD: ± 80mΩ

Output: ± 11µA

MTL4500 Series Barriers

Part Number

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514 (B)(D), MTL4516, MTL4516C, MTL4517, MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524, MTL4524S, MTL4525, MTL4526, MTL4531, MTL4532, MTL4533, MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4541T, MTL4544, MTL4544A, MTL4544AS, MTL4544B, MTL4544D, MTL4544S, MTL4546, MTL4546C, MTL4546S, MTL4546Y, MTL4549, MTL4549C, MTL4549Y, MTL4561, MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

MTL4500 range

Part NumberDescription

Digital Input modules

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514, MTL4514B, MTL4516,

MTL4516C, MTL4517

Digital Output modules

MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524,

MTL4524S, MTL4525, MTL4526

Pulse and Vibration modules

MTL4531, MTL4532, MTL4533

Analogue Input modules

MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4544, MTL4544A,

MTL4544AS, MTL4544B, MTL4544D, MTL4544S

Analogue Output modules

MTL4546, MTL4546C, MTL4546Y, MTL4549, MTL4549C, MTL4549Y

Fire and Smoke Interface modules

MTL4561

Temperature Input modules

MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581

General modules

MTL4599, MTL4599N
